NSD Absocoder NCV-220HFEM2R Specifications & Instruction Manual page 31

● In the case of using the commercially available cable (JKPEV-S 1.25mm
with a connector
Converter
NSD special cable
NSD special cable
Connector pin No.
and wire color
Pin Signal
Wire color
No. names
1 Brown SIN＋
2 SIN－
Red
3
Orange －COS＋
4 Yellow －COS－
5 Green OUT1＋
6 OUT1－
Blue
7 OUT2＋
Violet
8 OUT2－
Gray
9
－
10
－
11 Shield
Shield
12
－
Cautions for the connection by the connector
1: The wire No. of JKPEV-S cable is printed on the surface of the white wire.
2: Unused wires of JKPEV-S cable should be severed at both ends.
Please install the connector
by customers
Connector pin No. and wire color
Pin Wire No.
No. (pair)
1
1
2
3
2
4
5
3
6
7
4
8
5
－ 9
(Not used)
10
－
11
12
－ －
JKPEV-S Cable cross section
Commercially available cable
JKPEV-S cable
Signal
Wire color
names
White SIN＋
SIN－
Black
White －COS＋
Black －COS－
White OUT1＋
OUT1－
Black
OUT2＋
White
OUT2－
Black
White －
Black
－
Shield
Shield
－ －
26
2
×5P) and connecting
ABSOCODER sensor
ABSOCODER sensor
Connector pin No.
and wire color
Pin Wire Signal
No. color names
1 Brown SIN＋
2 SIN－
Red
3
Orange －COS＋
4 Yellow －COS－
5 Green OUT1＋
6 OUT1－
Blue
7 OUT2＋
Violet
8 OUT2－
Gray
9 －
10
－
11 Shield
Shield
12
－
－
－
－
