3. SPECIFICATIONS
3-1. Converter Specifications
● General Specification
Items
Power supply voltage
Power consumption
Insulation resistance
Withstand voltage
Vibration resistance
Ambient operating temperature
Ambient operating humidity
Ambient operating environment
Pollution degree
Corrosion immunity
Operating altitude
Ambient storage temperature
Grounding
Construction
Cooling
Outside dimension (mm)
Mass
*1: The converter is fixed by screws to the control cabinet. When the converter is mounted to the DIN rail, care must
be taken that vibrations or shocks will not occur. In an environment where repetitive or continuous vibration
occurs, be sure to take vibration-proofing measures.
*2: Pollution degree 2: This pollution doesn't conduct usually, but under certain circumstances temporary conductivity
occurs due to condensation (IEC61131-2).
24VDC±10% (including ripple)
7W or less
20 M-Ohms or more between external DC power terminals and ground
(by 500 VDC insulation resistance tester)
500 VAC, 60Hz for 1 minute between external DC power terminals and ground
Half amplitude: 0.15mm, constant acceleration: 19.6m/s
Two hours for each of three mutually perpendicular axes, total six hours
(IEC61131-2) (*1)
0 to +55°C (No freezing)
20 to 95 %RH (no condensation), transport condition: 5 to 95%RH (no condensation)
Free from corrosive gases and excessive dust
2 (IEC60664-1, IEC61131-2) (*2)
Not stained with organic solvents.
2000m or less above sea level (transport condition: 70kPa or more)
-25 to +70℃
Must be securely grounded (ground resistance of 100 ohm or less)
Book-shelf type within enclosure, DIN rail mountable
Air cooling
39(W) x 155(H) x 93(D) Refer to dimensions for details.
Approx. 0.4kg
