7-2. Function and Name of Display and Setting Area
(1) Monitor LED
Name
PWR LED turns ON when the power supply is normal status.
LED turns ON when the E-SX bus operates normal or the E-XS bus has a nonfatal fault. *1
ONL
LED blinks during initializing the E-SX bus".
ERR LED turns ON when the E-SX bus has an error. *1
ER1 LED turns ON when the axis-1 sensor is disconnected. *1
ER2 LED turns ON when the axis-2 sensor is disconnected. *1
This is a monitor of the current position setting command answerback signal for the axis-1.
LED turns ON during the current position setting for the axis-1.
PRA1
LED turns ON when the current position setting command button for the axis-1 is pressed on the panel or the
current position setting command for the axis-1 in the output data is "1".
This is a monitor of the current position setting command answerback signal for the axis-2.
LED turns ON during the current position setting for the axis-2.
PRA2
LED turns ON when the current position setting command button for the axis-2 is pressed on the panel or the
current position setting command for the axis-2 in the output data is "1".
Indicates a position data in a binary code.
0 to16 The axis-1 position data is displayed when the axis display selection switch is "1".
The axis-2 position data is displayed when the axis display selection switch is "2".
17 to 23 OFF
*1: The converter status can be checked by the lighting status of ONL, ERR, ER1, and ER2.
For more details, refer to "9-2-1. Check the error status".
(2) Axis display selection switch (DISPLAY)
Selects the position data which is displayed on the monitor LED on the panel.
- The axis-1 current position data is displayed on monitor LED when the switch is "1".
- The axis-2 current position data is displayed on monitor LED when the switch is "2".
