7. NOMENCLATURE
7-1. Part Identification
(1) Monitor LEDs
Power terminal block
(M4 screw)
(4) Error clear button
(5) Axis-1 current position
setting command button
Axis-1 sensor connector
Front face
(7) Parameter switch
(2) Axis display
(3) E-SX bus address
(6) Axis-2 current position
setting command button
Bottom face
29
selection switch
setting switch
Axis-2 sensor connector
IN side
E-SX bus connector
OUT side
E-SX bus connector
Rear face
ON
