Function Instructions
Protect Function
This receiver has low and high voltage protection function.
Low Voltage Protection: When the voltage is detected to be low, CH2 will not output and all the LED lights will
flash slowly for prompt.
High Voltage Protection: When the voltage is detected to be high, all channels will not output. All the LED lights
will flash fast for prompt.
The receiver ESC has overheating protection function.
Overheating Protection: When the internal temperature of the ESC is detected to be too high, CH2 will not output
and all the LED lights will flash fast for prompt. When the temperature is normal, the channel will resume output.
The receiver can return the battery voltage (high, medium, low, ultra-low) back to the transmitter side.
The transmitter can indicate the battery power status of the receiver after receiving the information returned by the
receiver.
本接收机具有电池电压过低和过高保护功能。
电压过低保护：当检测到电池电压过低时，CH2 通道无输出，所有车灯慢闪提示。
电压过高保护：当电池电压过高时，所有通道无输出，所有车灯快闪提示。
本接收机电调具有过热保护功能。
过热保护：当检测到电调内部温度过高时，CH2 通道无输出，所有车灯快闪提示；当温度正常后，通道恢复输出。
可将电池电压（高、中、低、过低）回传到发射机端。
用于发射机端指示接收机电池电量状态。
LED Lights Control
This receiver features 6 sets of LED lights: Turn signal left light, turn signal right light, daytime running light, headlight,
brake light and reverse light. And these 6 sets of LED lights are connected to this receiver through the FS-FMS-DB01
car light driver board.
The status of all the LED lights is controlled by the corresponding controls of the FS-FMS-MG6-BS transmitter. The
turn signal left light and turn signal right light are controlled by steering wheel. The daytime running lights and head-
lights are controlled by CH5 knob. The brake and reverse lights are controlled by throttle trigger. Details are as
follows:
本接收机支持 6 组车灯：左转灯、右转灯、日行灯、前大灯、刹车灯和倒车灯（此 6 组车灯通过 FS-FMS-DB01 车灯驱动板与本接
收机建立连接）。
车灯状态由 FS-FMS-MG6-BS 发射机的相应控件控制。左、右转向灯亮灭状态由手轮控制；日行灯和前大灯亮灭状态由CH5 旋钮控
制；刹车灯和倒车灯亮灭状态由扳机控制。具体有如下所述：
Notes:
1. After the receiver is turned on, all the lights will be on for one second and then go out.
2. The steering CH1 channel and throttle CH2 channel are capable of automatic neutral identifying, after the trim is
adjusted, the receiver should be powered again to recognize the neutral positions of these two channels automatically.
3. If you have set the steering channel in reverse, the trigger condition for turn signal left light and turn signal right light
will not be affected. And if you have set the CH5 channel in reverse, the trigger condition for daytime running lights and
headlights will not be affected.
注：
1. 接收机开机后，所有车灯常亮一秒后灭；
2. 方向通道 CH1 和油门通道 CH2 具有自动识别中位的功能 , 当调过微调后，需重新给接收机上电以完成中位自动识别；
3. 方向通道设置反向后对左、右转向灯控制无影响。CH5 通道设置反向后对日行灯和前大灯控制无影响。
功能说明
保护功能
车灯控制方式
