AJAX Button S Jeweller Manual page 8

removed from the device list of the old hub. This must be done through the Ajax
app.
Malfunctions
When a malfunction is detected, the Ajax app displays a malfunction counter on
the device icon. All malfunctions are shown in the button states. Fields with
malfunctions will be highlighted in red.
A malfunction is displayed if:
No connection with the hub or radio signal range extender via Jeweller.
The button battery is low.
Icons
The icons display some Button S states. To access them:
1. Sign in to the Ajax app
2. Select the hub.
3. Go to the Devices
Icon
Jeweller signal strength. Displays the signal strength between the hub and the
button. The recommended value is 2–3 bars.
Learn more
The button battery charge level is OK.
Learn more
The button has a malfunction. The list of malfunctions is available in the
button states.
Learn more
.
tab.
Meaning
