AJAX Button S Jeweller Manual page 10

Operating mode
LED Brightness
Accidental Press Protection
(displayed only for Panic and Mute Fire Alarm
operating modes)
You can check the battery charge by clicking on
the icon (displayed when the Battery Charge
Auto-Check option is enabled).
The feature is available when the
button is connected to all hubs
(except for the Hub model) with
rmware version OS Malevich
2.17 or higher.
How battery charge is displayed in
Ajax apps
How to replace a battery of the
button
Displays the operating mode of the button.
Three modes are available:
Panic.
Control.
Mute Fire Alarm.
Displays current brightness level of indicator
light:
Off (LED indication is disabled).
Low.
Max.
Displays the selected type of protection against
accidental activation:
Off — protection disabled.
Long press — to send an alarm you should
hold the button down for more than 1.5
seconds.
Double press — to send an alarm you should
double-press on the button with a pause of
