AJAX Button S Jeweller Manual page 6

devices will close/open the contacts for a set time. The operating mode and pulse
duration are set in the automation device settings.
8. Click Save. The scenario will appear in the list of device scenarios.
Mute Fire Alarm mode
By pressing Button S, the interconnected re detectors alarm can be muted (if
the corresponding operating mode of the button is selected). The reaction of the
system to pressing a button depends on the state of the system:
The Interconnected Fire Detectors Alarm has already propagated — by the
rst press of Button S, all re detectors sirens are muted, except for those
that registered the alarm. Pressing the button again mutes the remaining
detectors.
The interconnected alarms delay time lasts — the siren of the triggered Ajax
re detector is muted by pressing.
Learn more about Interconnected Fire Detectors Alarm
Adding to the system
Button S is incompatible with Hub, third-party security central panels, and ocBridge Plus
and uartBridge integration modules.
To connect Button S to the hub, the button must be located at the same secured
facility as the system (within the range of the hub radio network). For the button
to work via the ReX
button to the hub, then connect it to ReX or ReX 2 in the settings of the range
extender.
The hub and the device operating at different radio frequencies are incompatible. The
radio-frequency range of the device may vary by region. We recommend purchasing and
using Ajax devices in the same region. You can check the range of operating radio
frequencies with the
or ReX 2 radio signal range extender
technical support service
, you must rst add the
.
