SPX FLOW Bolting Systems PE55TWP-4-BS Operating Instructions And Parts List Manual page 34

Parts List Continued
ITEM PART NO.
1 10806
10804
2
2001708
3 10805
4 10133
10802
5
58841F
6 12356
7 10170
8 10438
10800
9
58841A
10 10439
11 10241
12 10169
13 40059WH2
© SPX FLOW, Inc.
DESCRIPTION
BRUSH HOLDER CAP
BRUSH (115 VAC)
BRUSH (230 VAC)
BRUSH HOLDER
KNURLED CUP SET SCREW
FIELD, 115 VOLT
FIELD, 230 VOLT
INTERNAL TOOTH WASHER
ROUND SCREW
BALL BEARING
115 VOLT ARMATURE
230 VOLT ARMATURE
BALL BEARING
LOCK WASHER
PAN SCREW
MOTOR BASE
QTY.
2
2
2
2
2
1
1
2
2
1
1
1
1
4
4
1
33
NOTES
Brush Holders (P/N 10805)
must be installed with slot and
dimple facing the open end of
the motor shell casing� Apply
Loctite® #680 or equivalent
between brush holder and
bore�
Stator must be installed with
p/n and date up (must be
visible through the rectangular
opening in the motor shell
casing�)
Parts need to be replaced, do
not use thread locker�
Press bearings into armature
and install as a unit into the
motor shell casing� Apply
Loctite® #277 or equivalent
between outer race and
bore� Place motor in upright
position while Loctite® #277 or
equivalent cures�
Counterclockwise rotation from
shaft in�
Press bearings into armature
and install as a unit into the
motor shell casing� Apply
Loctite® #277 or equivalent
between outer race and
bore� Place motor in upright
position while Loctite® #277 or
equivalent cures�
Torque to 2�5 Nm
(22 in-lbs�)
Form No. 1000679
Rev. 7 Nov. 6, 2023
