Parts List Continued
ITEM PART NO.
1 10020
2 33113
3 10361
4 10375
5 23547
6 23548
7 11228
8 11813
9 11814
10 23549
11 11955
12 11064
13 11261
14 23556
15 11821
16 23574
17 40072
18 10001
19 11198
20 10266
21 40071
22 10427
23 20774
24 21092
25 21093
26 10303
27 10425
28 20771
29 10271
30 12389
31 20849
32 23255
33 10426
34 23256
© SPX FLOW, Inc.
SCREW, 1/4-20 X 1�25 (Torque to 19-21 Nm (170-190 in-lbs�))
HIGH PRESSURE PUMP
SPRING COMPRESSION
STEEL BALL
BEARING TOP PLATE
TOP PLATE
THRUST BEARING
BEARING RACE
BALL BEARING
10 DEGREE ANGLE PLATE
SPRING SLOTTED PIN
NEEDLE BEARING
EXTERNAL RETAINING RING
SHAFT
WOODRUFF KEY
DRIVE GEAR
PUMP END PLATE
SCREW, #10-32 X 1�75 (Torque to 6-7 Nm (50-60 in-lbs�))
NEEDLE BEARING
O-RING
PUMP BODY
PLUG FITTING
DRIVE GEAR
ADAPTER
"C" KEY
O-RING
SPRING COMPRESSION
POPPET
O-RING
BACKUP WASHER
SPOOL
SPRING GUIDE
SPRING COMPRESSION
SPRING GUIDE
DESCRIPTION
29
QTY.
9
1
1
1
1
1
2
3
1
1
1
2
2
1
1
1
1
13
2
1
1
1
1
1
1
1
2
2
1
1
1
1
1
1
