Parts List Continued
ITEM PART NO.
1 9072
2 *251411
3 *251410
4 *252364
5 10008
6 10245
7 15456
8 18841
9 350431
10 21278-15
11 17147
12 10396
13 14725
14 351000
15 200609
16 1000543
17 65599BK2
18 3000646
19 40164
3000114
20
3000116
21091
Part numbers marked with an asterisk (*) are contained in valve assembly (No. 3000113)
© SPX FLOW, Inc.
GAUGE
QUICK PLUG COUPLER
QUICK COUPLER
DUST CAP
SCREW, 1/4-20 X 0�75 (Note: Apply Loctite ® #243 or equivalent to
threads and torque to 12-14 Nm (110-120 in-lbs�))
LOCK WASHER
STRAIGHT FITTING
STRAIGHT FITTING
FLUID LEVEL GAUGE
RELIEF VALVE
PLUG FITTING
JAM NUT
O-RING
DRAIN
DRAIN TUBE
SPX BOLTING SYSTEMS 6" x 2�6" DECAL
TANK PT 02�00 GAL
COVER PLATE ASSEMBLY (115 VAC)
RESERVOIR RECT GASKET
MOTOR CONTROL ASSEMBLY(115 VAC)
MOTOR CONTROL ASSEMBLY(230 VAC)
PARTS INCLUDED BUT NOT SHOWN
DRIVE COUPLING
22
DESCRIPTION QTY.
1
1
1
1
3
3
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
