Parts List Continued
ITEM PART NO.
1 215721
2 350943
3 251578
4 250637
5 215429
6 420891
7 *350944
8 *14874
9 *309079
10 215428
11 215431
12 215683
13 215693
14 *215430
15 10266
Part numbers marked with an asterisk (*) are contained in repair kit (No. 9633-KIT).
© SPX FLOW, Inc.
Pressure Regulator #420963
15
ADJUSTMENT STEM
(Note: Assemble to Locknut (Item #12) with Loctite® #242 or equivalent�)
BODY VALVE
KNURLED NUT
EXTERNAL RETAINING RING
COMPRESSION SPRING
REGULATOR BODY
FITTING SEAT
SOFT COPPER WASHER
POPPET
SPRING RETAINER
SPRING SLEEVE
(Note: Assemble closed coils of spring form towards fitting seat (Item #7))
REGULATOR LOCK NUT
KNOB
WASHER
O-RING
