Parts List Continued
ITEM PART NO.
1 22070
2 **11284
3 10362
4 209541
5 **12391
6 **10266
**12184
7
**12184
8 **2002148
9 **10269
10 **10268
11 **11863
12 21094
13 14426
14 12042
15 10361
16 12955
17 10375
18 251279
19 351200
20 212735
21 252164
22 252099
23 252053
24 10383
25 351257
26 10427
27 10854
28 421856BK
29 *251411
30 *252365
31 *251410
32 *252364
33 *10672
34 420902BK
35 11151
36 14844
37 10661
38 10479
39 1400-AA
40 65095BK
© SPX FLOW, Inc.
PISTON
O-RING
SPRING COMPRESSION
STEEL PLAIN WASHER
BACKUP WASHER
O-RING
BACKUP WASHER
BACKUP WASHER
SPOOL POPPET (Note: Assemble in this end only�)
O-RING
O-RING
BACKUP WASHER
BUSHING
SCREW, SHC 10-24 X 1�00 (Torque to 6-8 Nm (50-70 in-lbs�))
PLAIN COPPER WASHER
SPRING COMPRESSION
DOWEL PIN
STEEL BALL
PLUG FITTING (Torque to 14 Nm (120 in-lbs�))
REPLACEABLE SEAT
SCREW, HOL LCK 5/8-18 X 0�31 (Torque to 34 Nm (300 in-lbs�))
INSTRUCTIONS DECAL
SPECIAL WASHER
VALVE CAP (Torque to 34 Nm (300 in-lbs�))
HEX JAM NUT
BUSHING
PLUG FITTING (Torque to 28 Nm (250 in-lbs�))
SCREW, SHC 1/4-20 X 1�75 (Torque to 19 Nm (165 in-lbs�))
MANIFOLD BODY
QUICK PLUG COUPLER
DUST CAP
QUICK COUPLER
DUST CAP
STRAIGHT FITTING
LEFT END CAP
SCREW, SHC 10-24 X 1�25 (Torque to 6-8 Nm (50-70 in-lbs�))
STRAIGHT FITTING
STRAIGHT TUBE FITTING
PLUG FITTING
PLASTIC PACKAGING PLUG
VALVE BODY
DESCRIPTION
42
QTY.
4
8
4
4
8
5
4
1
2
1
4
4
2
4
1
1
1
1
1
1
1
1
1
1
1
1
2
2
1
4
4
4
4
4
1
4
1
1
1
1
1
