PERFORMANCE SPECIFICATION

The information in the following charts can be used as a basis to determine if the system is performing
as expected during operation�
Amp Draw at Amp Draw at dBA at Idle
Pump RPM 690 bar (10,000 psi) 690 bar (10,000 psi) and 690 bar
(115V) (230V) (10,000 psi)
PE55TWP-4-BS 12,000 25 15 90/89
Table 3. Drive Unit Requirements
Max. Fluid Delivery (cu. in./min.. @)
Pressure
Pump
7 bar 50 bar 70 bar 345 bar 690 bar
Output bar
0 bar (0 psi)
(100 psi) (700 psi) (1,000 psi) (5,000 psi) (10,000 psi)
(psi)
690 bar
PE55TWP-4-BS 704 - 440 - 74 56
(10,000 psi)
Typical delivery. Actual flow varies with field conditions.
Table 4. Fluid Pressure Chart
