EVAL-FFXMR20KM1HDR
Evaluation board description and getting started guide
System design
3.3

Bill of material

Please note that the detailed BOM of the EVAL-FFXMR20KM1HDR is available at www.infineon.com.
3.4

Connector details

Table 3 Connector X1
PIN Label
X1.1 +24VIN
X1.2 GND
Table 4 Connector X2
PIN Label
X2.1 SCL
X2.2 SDA
X2.3 P3VP
X2.4 SGND
X2.5 RDYC
X2.6 FLT#
X2.7 res.
X2.8 P15VP
X2.9 VCC1
X2.10 SGND
User guide
Function
24 V input
Input ground
Function
I C clock line
2
I C data line
2
Supply voltage for gate driver ICs primary side supply (shorted to
VCC1)
Ground for primary side
Connection to both RDYC pins of the gate driver ICs
Connection to both FLT# pins of the gate driver ICs
Not used
Supply voltage for the isolated power supply
Supply voltage for gate driver ICs primary side supply (shorted to
P3VP)
Ground for primary side
18 of 24 Revision 1.0
2023-03-27
