Peel-Off (Self-strip)
The EasyCoder PD4 can print on labels, tickets, tags, and continuous
stock in various forms. This section describes the case when self-adhesive
labels are separated from the liner immediately after printing. The liner is
then wound up on an optional integral liner takeup hub (see Chapter 6
"Options"). This is also known as "Self-strip" operation.
Peel-off can only be used for:
• Self-adhesive labels with liner
The label taken sensor can hold the printing of the next copy in the batch
until the present copy has been removed, see Chapter 2, "Installation;
Print Mechanism." The label taken sensor is enabled/disabled using the
ESim O command, see the ESim v5.xx for EasyCoder PD4, Programmer's
Reference Manual. The point of detection is approximately 15 mm (0.6
in) outside the inner edge of the media path.
Note: When using the printer for the first time or when chang-
ing to another media with different characteristics in regard
of label length, gap length, and liner transparency, you should
calibrate the label gap sensor and adjust the media feed in the
Autosensing Mode, see Chapter 9, "Adjustments", after you
have loaded the media. When loading a new roll of media from
the same stock as before, it is usually sufficient to press the Feed
key and feed out a label.
Note: When the liner rewinds to about 110 mm in diameter,
the liner roll will touch the max. liner rewind sensor and the
printer will stop printing until the liner has been removed from
the printer.
