Peel-Off, cont.
5
Align the media with the center section
and adjust the label feed guide. Flip the
guide back so it snaps to the rear label
feed rod and close the printhead.
7
Optionally, press the lower part of the
label taken sensor to flip it open.
Intermec EasyCoder PD4—User's Guide
Chapter 4—Loading Media
6
Put back the front cover and secure it
with the screw.
8
When in use, the label taken sensor
should be in a horizontal position.
27
