Intermec EasyCoder PD4 User Manual page 36

Chapter 4—Loading Media
Peel-Off, cont.
1
Unscrew the front cover screw and
remove the front cover.
3
Peel off the labels from the first 40 cm
(16 in) of the liner and route the liner
around the tear bar, then back under
the print mechanism and label feed rods
to the takeup hub.
26
2
Screw
Install the media as described for Tear-
4
Wrap the liner counterclockwise around
the takeup hub and secure it with the
Intermec EasyCoder PD4—User's Guide
Off operation #1 to #6 earlier in this
chapter.
U-shaped clip.
