Tickets with Gaps

⇐ a ⇒ Media Width
Maximum:
Minimum:
⇐ b ⇒ Copy Length
Maximum:
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
Minimum:
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
⇐ c ⇒ Detection Position
Variable:
⇐ d ⇒ Detection Slit Length
The length of the detection slit (excluding corner radii) must be mini-
mum 2.5 mm (0.10 inches) on either side of the detection position (e).
⇐ e ⇒ Detection Slit Height
Maximum:
Recommended:
Minimum:
Paper Type Setup
• Gap paper
Note: Do not allow any perforation to break the edge of the
media as this may cause the media to split and jam the printer.
Intermec EasyCoder PD4—User's Guide
Appendix B—Media Specifications
118.0 mm (4.65 inches)
25.0 mm (1.00 inches)
1270 mm (50 inches)
558.8 mm (22 inches)
5 mm (0.2) inches)
5 mm (0.2) inches)
0 to 57 mm (0 to 2.24 inches)
26.0 mm (1.02 inches)
3.0 mm (0.12 inches)
1.2 mm (0.05 inches)
79
