Ordering information

Error messages can be displayed in the "Diagnostics" standard
●
view of the SafeLogic compact Designer if you are connected to
the SafeLogic compact system.
For information on how to perform diagnostics see the "Rexroth
●
IndraControl SafeLogic compact Designer Software" operating in-
structions, chapter "Diagnostic view", see
ments" on page
Error displays and troubleshooting are described in detail in the
●
project planning manual "Rexroth IndraControl SafeLogic compact
Sercos Gateway", see
Do not open the housing!
Do not open the housing of the SafeLogic compact Sercos Gateway!

14 Maintenance

14.1 Cleaning notes

NOTICE
Do not use any solvents (e. g. diluents)!

14.2 Maintenance notes

The SafeLogic compact Sercos Gateway does not have to be maintained. The fol-
lowing needs to be checked at least annually at the SafeLogic compact Sercos
Gateway:
The correct position
●
The correct cabling (shielding and securing of Sercos cables)
●
Damage or rupture of the housing
●
The tight screw connection of the end brackets on the left and right of the
●
control
Replace the SafeLogic compact Sercos Gateway immediately when damaged.
15 Ordering information

15.1 Accessories and spare parts

For ordering information on accessories and spare parts, refer to
"Spare parts and accessories" on page
Bosch Rexroth AG R911338431_Edition 04
IndraControl SafeLogic compact Sercos
2.
tab. 1-2 "Related documents" on page
The SafeLogic compact Sercos Gateway is dam-
aged when using solvents!
7.
Gateway
tab. 1-2 "Related docu-
2.
chapter 5
