Bosch rexroth IndraControl SafeLogic compact Operating Instructions Manual page 24

20/27
Device description
LED Color
LINK/ Off
ACT1
Green
LINK/
Green/orange
ACT2
Tab. 12-1: LED to display the Ethernet connections XFE1 and XFE2
LED Color
MS Off
Green
Green (1 Hz) flashing
Red (1 Hz) flashing
Red (2 Hz) flashing
Red
Red/green (1 Hz) flashing
Tab. 12-2: Display of the operating state (module status)
LED Color
MOD Off
Red/green (1 Hz) flashing
Green (1 Hz) flashing
Green
Red (1 Hz) flashing
Red
NET Off
Green (1 Hz) flashing
Green
Red (1 Hz) flashing
Red
Tab. 12-3: Special displays for CIP Safety on Sercos
Bosch Rexroth AG R911338431_Edition 04
IndraControl SafeLogic compact Sercos
Status
No Ethernet connection
Ethernet connection is active, no data transfer
EtherNet connection active, data transmission
Status
No operating voltage or no communication with CPU module
"RUN"
"STOP"
Configuration required or configuration in progress
Safety-relevant error. Cause: Error detection using firmware
of the SafeLogic compact Sercos Gateway
Safety-relevant error. Cause: Error while communicating with
the CPU
"RUN", a non-safety-relevant error is present
Status
No operating voltage
Self-test
No configuration or application in the "STOP" state
Operating state. Application is in the "RUN" state
Recoverable error (e.g. configuration error)
Unrecoverable error. It is possible that the SafeLogic com-
pact Sercos Gateway has to be replaced (critical fault)
No operating voltage
A connection to the Sercos connection is established, but no
cyclic CIP Safety communication takes place
Cyclic CIP Safety communication (for at least one connec-
tion)
One or several CIP Safety connections report an error in the
cyclic communication (e.g. timeout, CRC)
No communication possible (e.g. Sercos bus is not in CP4)
Gateway
