Technical data
Transfer rate
MAC address

7.2 Voltage supply

The module bus connector supplies the SafeLogic compact Sercos Gateway with
power.
Supply voltage
Nominal current
Power consumption
Type of power supply

7.3 Safety-related characteristic parameters

Safety integrity level SIL
Category
Performance level PL
PFH (average frequency of a dangerous failure per
hour)
PFD (average probability of a dangerous failure
avg
in case of request)
Hardware error tolerance (HFT)
Service life T
M
MTTF (mean time to failure)
d
DC (average diagnostic coverage)
avg
Protection class
Degree of protection
Contamination level

7.4 Dimensions and weight

Dimensions (W × H × D)
Weight (without packaging)
Bosch Rexroth AG R911338431_Edition 04
IndraControl SafeLogic compact Sercos
100 MBit/s (100Base-TX)
Saved on electronic type plate, can be read out via
the configuration tool
24 V DC (16.8 V DC .... 24 V DC .... 30 V DC)
Typ. 110 mA (if nominal current is 24 V DC)
Max. 2.7 W
PELV or SELV (provided via SLC-3-CPU). For the
power supply unit requirements refer to the in-
struction "IndraControl SafeLogic compact Hard-
ware", see tab. 1-2 "Related documents" on page
2.
SIL 3 (IEC 61508)
Category 4 (EN ISO 13849-1)
PL e (EN ISO 13849-1)
0.4 × 10 -9 1/h
-5
3.5 × 10
1
20 years (EN ISO 13849)
The manufacturing ate is written on the type plate:
FD: Year/calendar week
2,500 years
99 % ≙ high
III (EN 61140)
IP 20 (EN 60529)
2 (EN 61131-2)
Ca. 22.5 × 96.5 × 120.8 mm
Ca. 130 g
Gateway
