6/27
Intended use
WARNING
Even though the control system was developed, manufactured and tested ac-
cording to the safety standards and certified by an accredited test institute, us-
ing this component does not automatically ensure a functionally safe machine.
The machine manufacturer still has to perform a risk analysis and provide safety
measures for risk reduction and to validate the operating method. The functional
safety can only be ensured by comprehensively implementing the requirements
(e.g. systematic measures, software requirements, integrating the sensors and
actuators) according to the applicable standards (EN ISO 13849 and EN 62061).
The SafeLogic compact Sercos Gateway may only be used by qualified personnel
and only at the machine at which the SafeLogic compact Sercos Gateway was
mounted and initially commissioned by qualified personnel according to this
operating instructions.
WARNING
Any warranty claim against the Bosch Rexroth AG shall be waived if the device is
modified or changed in any way - even within the framework of mounting or in-
stallation.
During the mounting, installation and usage of the SafeLogic com-
●
pact Sercos Gateway, comply with the standards and directives
applicable in your country
The national and international rules and regulations apply to the
●
installation and use as well as commissioning and periodic techni-
cal inspection of the modular SafeLogic compact safety control, in
particular:
– The low voltage directive 2014/35/EU
– Machine directive 2006/42/EC
– EMC directive 2014/30/EU
– Provision and use of work equipment directive 2009/104/EC
– The accident prevention regulations and safety rules
Only skilled personnel can execute the tests.
This operating instructions does not provide instructions on the op-
eration of the machine into which the Safety control is integrated.
For more information, refer to the operating instructions of the ma-
chine.
Bosch Rexroth AG R911338431_Edition 04
IndraControl SafeLogic compact Sercos
The SafeLogic compact Sercos Gateway is a
Safety module facilitating the transmission of
safety-relevant data via Sercos.
Comply with the safety instructions and safety
measures for the SafeLogic compact Sercos
Gateway!
Gateway
