IndraControl SafeLogic compact Sercos
Gateway
WARNING
The SafeLogic compact system meets the prerequisites for class A (industrial ap-
plications) according to the "emission" standard. The SafeLogic compact system
is thus only intended for use in an industrial environment.

4.1 UL/CSA applications

To be used in a Pollution Degree 2 environment only.
●
Use lines suitable for a temperature range between 60°C and 75°C. The max.
●
operating ambient temperature is 55°C.
For UL applications the device must be used with a Class 2 power supply or
●
Class 2 transformer in accordance with UL1310 or UL1585.
The power supply of the SafeLogic compact Sercos Gateway has to be execu-
●
ted by a power supply unit with protective separation, protected by a fuse ac-
cording to UL 248 with max. 100 V. V corresponds to the DC supply voltage
with a max. of 42.4 V DC. The UL 508 requirements are thus complied with.
The safety functions are not evaluated by UL. The approval is granted
according to UL 508, general applications.

5 Spare parts and accessories

5.1 Spare parts

There are no spare parts available for the SafeLogic compact Sercos Gateway.
The SafeLogic compact Sercos Gateway is not subject to any wear.

5.2 Accessories

The following cables can be used as connecting cable for Sercos interfaces ac-
cording to the current specifications of Sercos international:
Ordering code
RKB0007/002,5
RKB0007/005,0
RKB0007/010,0
Only use the SafeLogic compact system in an in-
dustrial environment!
Part number
R911170147
R911170148
R911170149
Spare parts and accessories
Description
Ethernet cable, 10-Base-T, CAT.5, crosslink,
ready-made, with RJ45 connector on both sides,
2.5 m
Ethernet cable, 10-Base-T, CAT.5, crosslink,
ready-made, with RJ45 connector on both sides,
5.0 m
Ethernet cable, 10-Base-T, CAT.5, crosslink,
ready-made, with RJ45 connector on both sides,
10.0 m
