About this documentation

1.2 Purpose

These operating instructions can only be used together with other SafeLogic
compact operating instructions (see
2). The operating instructions instructs the technical personnel of the ma-
chine manufacturer or machine operator on safe mounting, adjustment, electri-
cal installation, commissioning as well as on operation and maintenance of the
SafeLogic compact Sercos Gateway.
These operating instructions do not provide information on the operation of the
machine in which a SafeLogic compact modular safety control and a Sercos
gateway is integrated. For information on the operation, refer to the operating
instructions of the respective machine.

1.3 Qualifications

Required qualification: Individual who is able to assess the tasks assigned and to
identify possible safety risks owing to qualification in the subject, knowledge
and experience. The individual should also be familiar with the standards and
regulations.

1.4 Scope

These operating instructions apply to the SafeLogic compact Sercos Gateway
with the type code "SLC-3-GS3S00300".
The type code specifications are located on the type plate of the device, also re-
fer to chapter 2.1 "Product identification" on page

1.5 Related documents

The following operating instructions are available for the SafeLogic compact sys-
tem:
Document
Operating Instructions
Operating Instructions
Operating Instructions
Project Planning Manual Rexroth IndraControl SafeLogic compact Sercos
Tab. 1-2: Related documents

1.6 Customer feedback

Customer requests, comments or suggestions for improvement are of great im-
portance to us. Please email your feedback on the documentations to
Bosch Rexroth AG R911338431_Edition 04
Title
Rexroth IndraControl SafeLogic compact Hard-
ware
Rexroth IndraControl SafeLogic compact Diagnos-
tic Gateway
Rexroth IndraControl SafeLogic compact Designer
Software
Gateway
IndraControl SafeLogic compact Sercos
tab. 1-2 "Related documents" on page
3.
Gateway
Part number
R911332746
R911332752
R911332749
R911338436
