SFP Port
Power Supply
Input Leakage
Current
EEE
PoE
Reset Button
Power
Consumption
Temperature
Humidity
Number of Fans
Temperature
Alarm
Certification
Dimensions
(W x D x H)
Net Weight
Notice
Device operation in a residential environment may cause radio interference.
Product Appearance
On the front panel, the RG-NBS3100-24GT4SFP-V2 Ethernet switch provides twenty-four 10/100/1000Base-T
Ethernet ports and four SFP ports. On the back panel, it provides an AC power port.
Figure 1-1 Appearance of the RG-NBS3100-24GT4SFP-V2
The supported module type may change at any time. Consult Ruijie Networks for the
latest information.
1000Base-X
100Base-X
AC input
Rated voltage range: 100 V to 240 V
Maximum voltage range: 90 V to 264 V
Frequency: 50/60 Hz
Rated current: 0.6 A
≤
3.5 mA
Supported
Not supported
Press and hold the Reset button for less than 2 seconds: The switch restarts.
Press and hold the Reset button for more than 5 seconds until the system status LED
blinks: The Eweb login password is restored to the default password "admin". After the
user configurations are saved, the system restores to factory default settings and restarts.
Press and hold the Reset button for 2 to 5 seconds: No action is triggered.
21 W
Operating temperature: 0° C to 50° C (32° F to +122° F)
Storage temperature: -40° C to +70° C (-40° F to +158° F)
Operating humidity: 10% to 90% RH
Storage humidity: 5% to 95% RH
Fanlesss
Not supported
CE
440 mm x 165 mm x 44 mm
1.9 kg
2
Product Overview
