Installation Guide
Note

This device relies on the separate protective earthing terminal.

The device installation must be permanently grounded.

The device must be intended to be used in a location with equipotential bonding (such as a
telecommunication center, a dedicated computer room, or a restricted access area).
Heat Dissipation
The RG-NBS3100-24GT4SFP-V2 adopts natural heat dissipation, thereby ensuring normal operation. You
must reserve 10 cm distance space at both sides and the back plane of the cabinet to allow airflow. It is
recommended that you clean the device once every three months to avoid dust from blocking vents.
LED
LED
System status LED
10/100/1000Base-T
Ethernet port status
LED
SFP port status
LED
Panel
Identification
Status
1–24
25–28
State Meaning
Off The switch is not receiving power.
Blinking green The switch is running, but is not
(0.5 Hz) connected to Ruijie Cloud.
Blinking green The switch is being upgraded or
(10 Hz) initialized.
Solid green The switch is connected to Ruijie Cloud.
Off The port is not connected.
The port is connected at a rate of
Solid green
10/100/1000 Mbps.
The port is receiving or transmitting
Blinking green
traffic.
Off The port is not connected.
The port is connected at a rate of
Solid green
100/1000 Mbps.
The port is receiving or transmitting
Blinking green
traffic.
