Ruijie Reyee RG-NBS3100-24GT4SFP-V2 Installation Manual page 31

Installation Guide
GE-SFP-LX20-SM1550-
BIDI
GE-SFP-LH40-SM1310-
BIDI
GE-SFP-LH40-SM1550-
BIDI
MINI-GBIC-ZX50-SM155
0
MINI-GBIC-ZX80-SM155
0
MINI-GBIC-ZX100-SM15
50
GE-SFP-SX
GE-SFP-LX
Mini-GBIC-GT
Note

For the optical module with the transmission distance exceeding 40 km or above, add one online optical
attenuator on the link to avoid the overload of the optical receiver when short single-mode optical fibers
are used.

Optical modules generate laser. Do not look directly into the optical module.

To keep optical modules clean, use dust caps when the modules are not connected to
Table B-4 Specifications of SFP BIDI Optical Module Pairs
Rate/Distance
1000 Mbps/500 m
1000 Mbps/20 km
1000 Mbps/40 km
Caution
The BIDI modules must be used in pairs, for example, FE-SFP-LX20-SM1310-BIDI and
FE-SFP-LX20-SM1550-BIDI are used together.
LC SMF
LC SMF
LC SMF
LC SMF
LC SMF
LC SMF
LC MMF
LC SMF
RJ45 cable Category 5 (or above) UTP/STP
25
Appendix B Mini-GBIC and SPF Module
9/125
9/125
9/125
9/125
9/125
9/125
62.5/125
50/125
9/125
Module Pairs
GE-SFP-SX-SM1310-BIDI
GE-SFP-SX-SM1550-BIDI
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
20 km
40 km
40 km
50 km
80 km
100 km
275 m
550 m
10 km
100 m
cables.
