NSD ABSOCODER NCW-3DHIPM2R Specifications & Instruction Manual page 96

General Status
Code (in hex)
Service fragmentation sequence
17
not in progress
18 No stored attribute data
19 Store operation failure
Routing failure, request packet too
1A
large
Routing failure, response packet
1B
too large
1C Missing attribute list entry data
1D Invalid attribute value list
1E Embedded service error
1F Vendor specific error
20 Invalid parameter
Write-once value or medium
21
already written
22 Invalid Reply Received
23 Buffer Overflow
24 Message Format Error
25 Key Failure in path
26 Path Size Invalid
27 Unexpected attribute in list
28 Invalid Member ID
29 Member not settable
Status Name
The fragmentation sequence for this service is not currently active for
this data.
The attribute data of this object was not saved prior to the requested
service.
The attribute data of this object was not saved due to a failure during
the attempt.
The service request packet was too large for transmission on a network
in the path to the destination. The routing device was forced to abort the
service.
The service response packet was too large for transmission on a
network in the path from the destination. The routing device was forced
to abort the service.
The service did not supply an attribute in a list of attributes that was
needed by the service to perform the requested behavior.
The service is returning the list of attributes supplied with status
information for those attributes that were invalid.
An embedded service resulted in an error.
A vendor specific error has been encountered. The Additional Code
Field of the Error Response defines the particular error encountered.
Use of this General Error Code should only be performed when none of
the Error Codes presented in this table or within an Object Class
definition accurately reflect the error.
A parameter associated with the request was invalid. This code is used
when a parameter does not meet the requirements of this specification
and/or the requirements defined in an Application Object Specification.
An attempt was made to write to a write-once medium (e.g. WORM
drive, PROM) that has already been written, or to modify a value that
cannot be changed once established.
An invalid reply is received (e.g. reply service code does not match the
request service code, or reply message is shorter than the minimum
expected reply size). This status code can serve for other causes of
invalid replies.
The message received is larger than the receiving buffer can handle.
The entire message was discarded.
The format of the received message is not supported by the server.
The Key Segment that was included as the first segment in the path
does not match the destination module. The object specific status shall
indicate which part of the key check failed.
The size of the path which was sent with the Service Request is either
not large enough to allow the Request to be routed to an object or too
much routing data was included.
An attempt was made to set an attribute that is not able to be set at this
time.
The Member ID specified in the request does not exist in the specified
Class/Instance/Attribute.
A request to modify a non-modifiable member was received.
Description of Status
87
(2/3)
