APPENDIX 2. DETAILS OF CIP OBJECT

Data handled by NCW-3DHIP supporting Ethernet / IP is managed by CIP object.
Access the CIP object using various services that are installed in each CIP object.

APPENDIX 2-1. Identity Object (Class ID: 0x01)

It holds NCW - 3DHIP node information on the network.
The specification of the Identity object is shown below.
Identity object has one instance.
Class Attribute (Class ID: 0x01)
ID
0x01 Revision
0x02 Max Instance
0x03 Number of Instances
Class Service (Class ID: 0x01, Instance ID: 0x00)
ID
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
Instance Attribute (Class ID: 0x01, Instance ID: 0x01)
ID
0x01 Vendor ID
0x02 Device Type
0x03 Product Code
0x04 Revision
0x05 Status
0x06 Serial Number
0x07 Product Name
Access
Name
Get
○
○
○
Name
Read out all attribute values from NCW-3DHIP.
Responded Attribute information for the request is following;
ID
0x01
0x02
0x06
0x07
Read out one attribute value from NCW-3DHIP.
Access
Name
Get
○
○
○
○
○
○
○
Data Type
Set
- UINT 1
- UINT 1
- UINT 1
1 (Revision)
1 (Max Instance)
0 (Not available for NCW-3DHIP)
0 (Not available for NCW-3DHIP)
Data Type
Set
UINT
Indicates the product vendor ID. (230: NSD Corporation)
－
UINT
Indicates the product device type. (43: Generic Device)
－
UINT
Indicates the product code. (30101)
－
USINT
Indicates the product major revision.
－
USINT
Indicates the product minor revision.
WORD
Indicates the product status.
－
*1: Please refer to the next page for definition of Bit.
UDINT
Indicates the product serial number.
－
SHORT_
Indicates the product name. (NCW-3DHIPM2R)
－
STRING
102
