2. MODEL SELECTION WHEN ORDERING

The following figure indicates the connection configuration of NCW-3DHIP.
Before ordering, refer to the connection configuration and model list. Please prepare by customer except (1) to (5) in
the connection configuration.
● Connection configuration
EtherNet/IP master
( PLC, Industrial PC )
Configuration Tool
(5) EDS File
(3) Extension sensor cable
In the case of using the NSD special cable
In the case of using the commercially available cable
(1) NCW-3DHIP
( EtherNet/IP slave)
(2) ABSOCODER sensor
Connector
type
B
R
P
R
3
EtherNet/IP slave
(4) Option
MRE-[ ]SP061 L type flange for
MRE-[ ]SP074 MRE-[ ]SP061
MRE-[ ]SP097
MRE-[ ]SP101
RB-01
