8-2-1. Contents of the communication status indicator area

Explains the overview of the Ethernet/IP communication status indicator area.
For more details, refer to "11. TROUBLE SHOOTING".
Indicator Color
MS Green/Red
NS Green/Red
L/A1 Green
L/A2 Green
Light status
OFF
Steady Green
Flashing Green
Flashing Red
Steady Red
Flashing Green / Red
OFF
Flashing Green
Steady Green
Flashing Red
Steady Red
Flashing Green / Red
OFF
ON
Flashing
OFF
ON
Flashing
Description
No power
Normal operation
No IP address
A recoverable fault occurs
An unrecoverable fault occurs
Self test in progress
Not powered, no IP address
No connection is established
Connection is established
Connection timeout occurs
IP address is duplicated
Self test in progress
LINK1 port: No link
LINK1 port: Link
LINK1 port: Link (during the communication)
LINK2 port: No link
LINK2 port: Link
LINK2 port: Link (during the communication)
