APPENDIX 2-12. Info Maintenance Object (Class ID: 0xC7)

Stores NCW-3DHIP maintenance information in this object.
The maintenance information is saved in the non-volatile memory.
Following tables indicate specifications of the Info Maintenance object.
The Info Maintenance object has one instance.
Class Attribute (Class ID: 0xC7)
ID Name
0x01 Revision
0x02 Max Instance
0x03 Number of Instances
Class Service (Class ID: 0xC7, Instance ID: 0x00)
ID Name
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
Instance Attribute (Class ID: 0xC7, Instance ID: 0x01)
ID Name
0x01 Power Distribution Time
0x02 Function
0x03 Location
0x04 Installation Date
0x05 Descriptor1
0x06 Descriptor2
0x07 Security
Instance Service (Class ID: 0xC7, Instance ID: 0x01)
ID Name
0x0E Get_Attribute_Single
0x10 Set_Attribute_Single
Access
Data Type
Get Set
○ UINT
－
○ UINT
－
○ UINT
－
Read out all attribute values from NCW-3DHIP.
Read out one attribute value from NCW-3DHIP.
Access
Data Type
Get Set
○ UDINT
－
○ ○ Structure
UDINT
STRING
○ ○ Structure
UDINT
STRING
○ ○ Structure
UDINT
STRING
○ ○ Structure
UDINT
STRING
○ ○ Structure
UDINT
STRING
○ ○ Structure
UDINT
STRING
Read out one attribute value from NCW-3DHIP.
Write one attribute value to NCW-3DHIP.
133
Description
1
1
1
Description
Description
NCW-3DHIP cumulative energization time can be check.
Unit: sec
Function information
Stores a function code.
Stores a function comment.
(Max.character No.: 58)
Installation location information
Stores an installation location code.
Stores an installation location comment.
(Max.character No.: 58)
Installation date information
Stores installation date code.
Stores installation date comment.
(Max.character No.: 58)
Descriptor1 information
Stores a descriptor 1 code.
Stores a descriptor 1 comment.
(Max.character No.: 58)
Descriptor2 information
Stores a descriptor 2 code.
Stores a descriptor 2 comment.
(Max.character No.: 58)
Security information
Stores a security code.
Stores a security name comment.
(Max. character No.:58)
