9. EtherNet/IP COMMUNICATION SETUP

9-1. Procedure Before the Operation

Indicates procedure before the operation
Start setup
Preparation
Set the NCW-3DHIP
communication speed and
format.
Set the IP address
Set the EtherNet/IP driver
Set the network
configuration
Set the parameter
Set the preset
(Current position setting)
Check the positon data
Finish setup
Note
When setting parameters, switch the operation mode of the host PLC to program mode (PROG).
Cannot be set in run mode (RUN).
This operation is performed by using the PLC's configuration tool (a PLC development tool software).
*: Depending on the PLC model, this operation can also be performed by the mode selection switch on the CPU card.
-------- Refer to section 9-2.
Download the EDS file (text file) from NSD web site.
URL: www.nsdcorp.co.jp
-------- Refer to section 9-3.
Set the NCW-3DHIP communication speed and format.
-------- Refer to section 9-4.
Set the IP address either the following methods.
- Set by the rotary switch on the NCW-3DHIP panel side.
- Set from BOOT/DHCP server.
-------- Refer to section 9-5.
Set the EtherNet/IP driver.
-------- Refer to section 9-6.
Set the network configuration of EtherNet/IP including PLC
(EtherNet/IP master) and NCW-3DHIP.
-------- Refer to section 9-7.
Set the NCW-3DHIP parameter.
-------- Refer to section 9-7.
Set the current position value by using the preset
function in the parameter setting.
-------- Refer to section 9-8.
Check the position data is counted correctly.
