Using Flash PC Cards

Removing a GBIC

Two physical GBIC models are available. One GBIC model has a locking handle to secure the GBIC in
the module; the other model uses two clips, one on each side of the GBIC. This section contains
procedures for removing both GBIC models.
Removing a GBIC with Clips
Warning Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into
beams or view directly with optical instruments.
If you are removing a GBIC with clips, perform these steps:
Disconnect the network fiber-optic cable from the GBIC SC connector.
Step 1
Release the GBIC from the slot by simultaneously squeezing the two plastic tabs (one on each side of
Step 2
the GBIC).
Slide the GBIC out of the Gigabit Ethernet module slot. A flap drops down to protect the Gigabit
Step 3
Ethernet module connector.
Place the GBIC in an antistatic bag.
Step 4
Removing a GBIC with a Handle
Invisible laser radiation may be emitted from disconnected fibers or connectors. Do not stare into
Warning
beams or view directly with optical instruments.
If you are removing a GBIC with a handle, perform these steps:
Step 1 Disconnect the network fiber-optic cable from the GBIC SC connector.
Step 2 Rotate the handle up to release the GBIC from the slot.
Grip the handle or the sides of the GBIC and slide the GBIC out of the slot. A flap drops down to protect
Step 3
the slot.
Step 4 Place the GBIC in an antistatic bag.

Using Flash PC Cards

To use a Flash PC card with the supervisor engine, you must format the card with the supervisor engine.
Note
Book Title
3-20
Chapter 3 Installing Modules
OL-5077-7
