Chapter 1 Product Overview
Table 1-2
Supervisor Engine
Route Switch Processor 720
(RSP720-3C-GE)
Route Switch Processor 720
(RSP720-3CXL-GE)
1. The WS-SUP720-3BXL requires larger power supplies and high-speed fans; for information see
http://www.cisco.com/univercd/cc/td/doc/product/core/cis7600/hardware/cis_76xx/remrep.htm
#1098824.
OL-5077-7
Supervisor Engines (continued)
Features
Two Gigabit Ethernet uplink ports: port 1
•
supports a 1-Gbps small form pluggable
(SFP) module; port 2 is configurable with
either a 1-Gbps SFP module or a
10/100/1000-Mbps RJ-45
• Integrated 720-Gbps switch fabric
• PFC3C and MSFC4 with 512-MB bootflash,
4-MB NVRAM, 4-MB ROMMON, and
several DRAM options:
Route processor (RP): 1- to 4-GB
•
DRAM (default 1 GB)
Switch processor (SP): 1- to 2-GB
•
DRAM (default 1 GB)
2 CompactFlash Type II slots (on front
•
panel) and 2-GB internal CompactFlash (1
GB each for RP and SP)
• Requires larger power supplies and a
high-speed fan tray
• QoS port architecture (Rx/Tx) is
1p1q4t/1p2q2t
• Two Gigabit Ethernet uplink ports: port 1
supports a 1-Gbps small form pluggable
(SFP) module; port 2 is configurable with
either a 1-Gbps SFP module or a
10/100/1000-Mbps RJ-45
Integrated 720-Gbps switch fabric
•
PFC3CXL (high-capacity) and MSFC4 with
•
512-MB bootflash, 4-MB NVRAM, 4-MB
ROMMON, and several DRAM options:
• Route processor (RP): 1- to 4-GB
DRAM (default 2 GB)
• Switch processor (SP): 1- to 2-GB
DRAM (default 1 GB)
• 2 CompactFlash Type II slots (on front
panel) and 2-GB internal CompactFlash (1
GB each for RP and SP)
Requires larger power supplies and a
•
high-speed fan tray
QoS port architecture (Rx/Tx) is
•
1p1q4t/1p2q2t
Supervisor Engines
