Catalyst 6500 Family Modules

Table 1-16 MT-RJ OSM Interface LED Descriptions
LED Color
LINK
Green
Off
Green
Yellow
CARRIER
ALARM
Off
Catalyst 6500 Family Modules
All Catalyst 6500 family modules are supported on the Cisco 7600 series router. For information on
Note
Catalyst 6500 family modules, refer to the Catalyst 6500 Series Switch Module Guide at
http://www.cisco.com/en/US/products/hw/switches/ps708/products_module_configuration_guide_boo
k09186a008036fa45.html.
This section describes the recommended Catalyst 6000 family modules for the Cisco 7600 series router:
•
•
•
•
•
•
•
•

FlexWAN Module (WS-X6182-2PA)

The FlexWAN module is not fabric-enabled. When a Switch Fabric Module is installed in the
Note
Cisco 7600 series router, and there is a mix of fabric-enabled and non-fabric-enabled (classic) modules
in the system, the central forwarding performance remains at 15 Mbps.
The MSFC2, in conjunction with the FlexWAN module (WS-X6182-2PA), provides multiprotocol
routing support with full Internet route connectivity for speeds ranging from serial RS-232 to OC-3. The
FlexWAN module can accept up to two Cisco 7200 or Cisco 7500 WAN port adapters, which deliver
Book Title
1-24
Description
Indicates that the port has been configured and enabled.
The port has been configured and enabled to operate.
The port has not been configured or enabled to operate.
Indicates that the port detects a valid SONET signal.
A valid SONET signal has been detected with no alarm conditions.
A valid SONET signal has been detected, but there are alarm conditions
present (such as LRFI, PRFI, LOS, LOF, LOP, LAIS, PAIS, or Signal
Label Mismatch).
No valid SONET signal is detected.
FlexWAN Module (WS-X6182-2PA), page 1-24
Enhanced FlexWAN Module (WS-X6582-2PA), page 1-25
48-Port 10/100TX Switching Module (WS-X6348-RJ-45), page 1-26
16-Port Gigabit Ethernet Switching Module (WS-X6516-GBIC), page 1-26
Switch Fabric Module (WS-C6500-SFM), page 1-27
Switch Fabric Module 2 (WS-X6500-SFM2), page 1-27
Cisco Application Control Engine (ACE) Module (ACE10-6500-K9), page 1-28
Catalyst 6000 Family Module LED Descriptions, page 1-29
Chapter 1 Product Overview
OL-5077-7
