Port Densities

Figure 2-7
Figure 2-8
Port Densities
Table 2-9
Table 2-9
Architecture
Backplane Bandwidth
for Supervisor Engine
32
Backplane Bandwidth
for Supervisor Engine
720
Backplane Bandwidth
for Supervisor Engine
RSP720
Number of Gigabit
Ethernet ports
Number of OC-3 POS
ports
Number of OC-12 POS
ports
Number of OC-48 POS
ports
Number of OC-12 ATM
ports
Book Title
2-18
RJ-45 Interface Cable Connector
1
Pin 8
Mini-SMB Connector
lists the bandwidth and port densities of the Cisco 7600 series routers.
Cisco 7600 Series Router Bandwidth and Port Density
Cisco 7603 Cisco 7604
Router Router
32 Gbps 32 Gbps
720 Gbps 720 Gbps
720 Gbps 720 Gbps
34 50
32 48
8 12
2 3
4 6
RJ-45 (both ends)
Cisco 7606 Cisco 7609
Router Router
32 Gbps 32 Gbps
720 Gbps 720 Gbps
720 Gbps 720 Gbps
82 130
80 128
20 32
5 8
10 16
Chapter 2 Preparing for Installation
Cisco 7609-S Cisco 7613
Router Router
32 Gbps 32 Gbps
720 Gbps 720 Gbps
720 Gbps 720 Gbps
130 194
128 192
32 48
8 12
16 24
