Installation Manual
Catalyst 6509-NEB Switch and Cisco OSR-7609
Router Upgrade Note
Product Number: WS-6509-NEB-UPGRD=
This publication describes how to upgrade your Catalyst 6509-NEB switch or Cisco OSR-7609 Router
to use the Supervisor Engine 720 and the Supervisor Engine 32.
AC-Input Systems—If your switch or router is using an AC-input power supply, you are required to
Note
install the WS-CAC-3000W power supply. The 3000 W AC-input provides a power output to power the
fan tray.
DC-Input Systems—If your switch or router is using a DC-input power supply, you are required to
Note
install the WS-CDC-2500W or PWR-4000-DC power supply. You must provide a separate, direct
connection to power the fan tray. Each input of the fan tray is rated 10 A @ -40 to -60 VDC.
Caution
It is important that you follow the steps in this document in the order they are presented.
Corporate Headquarters:
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2004–2006 Cisco Systems, Inc. All rights reserved.
Advertisement
Table of Contents
Related Manuals for Cisco OSR-7609
Summary of Contents for Cisco OSR-7609
- Page 1 Router Upgrade Note Product Number: WS-6509-NEB-UPGRD= This publication describes how to upgrade your Catalyst 6509-NEB switch or Cisco OSR-7609 Router to use the Supervisor Engine 720 and the Supervisor Engine 32. AC-Input Systems—If your switch or router is using an AC-input power supply, you are required to Note install the WS-CAC-3000W power supply.
-
Page 2: Table Of Contents
Before performing any of the following procedures, ensure that power is removed from the DC circuit. Warning Statement 1003 This unit might have more than one power supply connection. All connections must be removed to Warning de-energize the unit. Statement 1028 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note 78-16162-02... -
Page 3: Parts List
Two cables are provided for systems with redundant power supplies. Required Tools These tools are required to perform the installation: Number 1 Phillips-head screwdriver • Number 2 Phillips-head screwdriver • Flat-blade screwdriver (for DC-input systems) • 78-16162-02 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Parts List... -
Page 4: Installation Guidelines
Upload the current configuration to a server. On any modules running Cisco IOS, save the running Step 1 configuration. Warning Before working on a system that has an on/off switch, turn OFF the power and unplug the power cord. Statement 1 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note 78-16162-02... -
Page 5: Replacing The Panel Safety Cover
Replacing the Panel Safety Cover This section describes how to remove and install the panel safety cover for the Catalyst 6509-NEB switch and Cisco OSR-7609 Router. A number 1 Phillips-head screwdriver is required to perform this procedure. Always use an ESD wrist strap when handling modules or coming into contact with internal components. - Page 6 Use a number 1 Phillips-head screwdriver to install the 8 panel screws, 4 each located along the top and Step 4 bottom of the chassis. (See Proceed to the “Replacing the Fan Tray” section on page 7 Step 5 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Panel handle Figure to replace the fan tray. 78-16162-02...
-
Page 7: Replacing The Fan Tray
This section describes how to remove and install the fan tray for the Catalyst 6509-NEB switch and Cisco OSR-7609 Router. The standard fan tray (WS-C6509-NEB-FAN) must be removed and replaced with the high-speed fan tray (WS-C6509-NEB-FAN2). A flat-blade or number 2 Phillips-head screwdriver is required to perform this procedure. -
Page 8: Removing The Fan Tray
Once the fans have stopped spinning, pull the fan tray out further and support the underside of the fan Step 3 tray with the other hand. Pull the fan tray clear of the chassis, and put it in a safe place. Step 4 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Figure Captive installation screw INPUT... - Page 9 FAN FAIL INPOUT POWER GOOD RTN -48VDC GND INPUT OUTPUT FAIL “Replacing the Power Supply” section on page 10 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Replacing the Fan Tray Figure INPUT OUTPUT FAIL to replace the power supply.
-
Page 10: Replacing The Power Supply
AC power connection Cable retention device Power switch Captive installation Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note “Connecting Site Power to the Fan Tray for DC-Input Systems” section on Figure INPU T OUT PUT FAIL Status LEDs screw... - Page 11 48V INPUT 1 HIGH SPEE D FAN STATUS 48V INPUT 2 INPOUT POWER GOOD RTN -48VDC GND FAN FAIL INPOUT POWER WS-C6 500-NE B-FAN2 GOOD RTN -48VDC GND INPUT OUTPU T FAIL Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note 78-16162-02...
- Page 12 Grasp the power supply handle with one hand. Place your other hand underneath the power supply, as Step 3 shown in Figure is fully seated in the bay. Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note 110-12 0V - 15A 200-24 0V - 15A 60/50H Z OUTP UT 42V /17A...
-
Page 13: Connecting Power To The Fan Tray
INPOUT POWER GOOD RTN -48VDC GND OUTPUT 42V “Connecting Power to the Fan Tray” section on page 13 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Connecting Power to the Fan Tray Figure to connect power to the high... - Page 14 If you have redundant power supplies, repeat the steps in this section for the redundant power supply. Step 4 Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Figure 9) to the fan tray wire connector. Press...
- Page 15 Figure Terminal block covers HIG H SPE ED FAN 48V INPU T 2 FAN FAIL INPUT POWER GOOD RTN -48VD C GND Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Connecting Power to the Fan Tray 11.) Figure 12.)
- Page 16 Connect the DC-input wires to the terminal block (see Ground • Negative (-) • Positive (+) • Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Terminal block cover GN D INP UT PO WE R GO OD Figure Figure 14) in this order: 13.)
-
Page 17: Replacing The Supervisor Engine
78-16162-02 GN D INP UT PO WE R GO OD Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Replacing the Supervisor Engine... - Page 18 45 degrees with respect to the supervisor engine faceplate. (See Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note “Removing the Supervisor Engine” section on page...
- Page 19 48V INPUT 2 FAN FAIL INPOUT POWER GOOD RTN -48VDC GND gasket gasket 110-120V - 15A 200-240V - 15A 60/50HZ OUTPUT 42V INPUT OUTPUT FAIL Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Replacing the Supervisor Engine Figure 16.)
- Page 20 RTN -48VDC GND WS-C650 0-NEB-FA N2 Press left Press left 110-120V - 15A 200-240V - 15A 60/50HZ Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note HIGH SPEED FAN 48V INPUT 2 FAN FAIL INPOUT POWER GOOD RTN -48VDC GND...
-
Page 21: Powering Up The System
78-16162-02 HIGH SPE ED FAN 48V INPUT 2 FAN FAIL INPOUT POWER GOOD RTN -48VDC GND Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note Powering Up the System... -
Page 22: Verifying Installation
If the STATUS LED remains orange or turns red, the supervisor engine has not successfully completed the boot process and may have encountered an error. Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note 78-16162-02... -
Page 23: Related Documentation
This document is to be used in conjunction with the documents listed in the CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is a service mark of Cisco Systems, Inc.;... - Page 24 Obtaining Documentation and Submitting a Service Request Catalyst 6509-NEB Switch and Cisco OSR-7609 Router Upgrade Note 78-16162-02...
