Supervisor Engines
Table 1-5 Supervisor Engine 32 LEDs (continued)
LED Color
1
SYSTEM Green
Orange
Red
Blinking
Red
ACTIVE
Green
Orange
1
PWR MGMT Green
Orange
Red
LINK Green
Orange
Flashing
orange
Off
DISK
Green
1. The SYSTEM and PWR MGMT LED indications on a redundant supervisor engine are synchronized to the active supervisor
engine.
Table 1-6 Route Switch Processor 720 LEDs
LED Color
STATUS
Green
Orange
Yellow
Red
1
SYSTEM
Green
Orange
Red
Blinking
Red
ACTIVE Green
Book Title
1-14
Description
All chassis environmental monitors are reporting OK.
The module is powering up or a minor hardware fault has occurred.
Major hardware problem.
The temperature of the supervisor engine major threshold has been
exceeded.
Continuous backplane stall.
The module is operational and active.
The module is powering up or is in standby mode.
Sufficient power is available for all modules.
The module is powering up or has minor hardware problems.
Major hardware problem.
The port is operational.
The port is disabled.
The port is bad.
The module is powering up or the port is enabled and there is no link.
The disk is active.
Description
All diagnostics pass; the module is operational (normal initialization
sequence).
The module is booting or running diagnostics (normal initialization
sequence).
Minor hardware problems.
An overtemperature condition has occurred. (A major threshold has
been exceeded during environmental monitoring.)
All chassis environmental monitors are reporting OK.
The module is powering up or a minor hardware fault has occurred.
Major hardware problem.
The temperature of the supervisor engine major threshold has been
exceeded.
Continuous backplane stall.
The module is operational and active.
