NSD ABSOCODER NCW-3DNIPMP Specifications & Instruction Manual page 61

(2) The "Select Module Type" dialog box appears
(3) Select "ETHERNET-MODULE"
(4) Click "Create".
(5) The "New Module" dialog box appears
(6) Enter the information of "ETHERNET-MODULE" which is newly added.
- Name
- Description
- Comm Format
- IP Address
(7) Enter value to the connection parameter as follows.
(8) Click "OK".
(4)
(6)
(8)
52
(3)
(7)
