APPENDIX 2-8. TCP/IP Interface Object (Class ID: 0xF5)

The TCP/IP interface object provides Ethernet TCP/IP interface information.
The TCP/IP Interface Object provides the mechanism to configure the NCW-3DNIP's TCP/IP network interface
(IP address, network mask, and gateway address).
Following tables indicate specifications of the TCP/IP Interface object.
The TCP/IP Interface object has one instance.
Class Attribute (Class ID: 0xF5)
ID Name
0x01 Revision
0x02 Max Instance
0x03 Number of Instances
Class Service (Class ID: 0xF5, Instance ID: 0x00)
ID Name
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
Instance Attribute (Class ID: 0xF5, Instance ID: 0x01)
ID Name
0x01 Status
Access
Data Type
Get Set
○ UINT
－
○ UINT
－
○ UINT
－
Read out all attribute values from NCW-3DNIP.
Read out one attribute value from NCW-3DNIP.
Access
Data Type
Get Set
○ DWORD
－
111
Description
4
1
1
Description
Description
Current status of NCW-3DNIP
This attribute value changes due to the converter state.
Bit Description
0-3
Interface Configuration Status
Indicates the status of the Interface Configuration
Attribute.
0: The Interface Configuration attribute has not
been configured.
(It doesn't occur for NCW-30DNIP.)
1: The Interface Configuration attribute contains
configuration obtained from BOOTP, DHCP or
non-volatile storage.
2: The IP address member of the Interface
Configuration attribute contains configuration,
obtained from hardware settings.
3-15: Reserved
4
Mcast Pending
NCW-30DNIP doesn't support.
(Fixed at 0)
5
Interface Configuration Pending
TRUE (1) when Interface Configuration attribute
values are changed. The NCW-3DNIP requires a
restart in order for the configuration change to take
effect.
(1/4)
