APPENDIX 2-4. Connection Manager Object (Class ID: 0x06)

The Connection Manager object manages the communication status, and has one instance.
Following tables indicate specifications of the Connection Manager object.
Class Attribute (Class ID: 0x06)
ID Name
0x01 Revision
0x02 Max Instance
0x03 Number of Instances
Class Service (Class ID: 0x06, Instance ID: 0x00)
ID Name
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
Instance Attribute (Class ID: 0x06, Instance ID: 0x01)
ID Name
0x01 Open Requests
0x02 Open Format Rejects
0x03 Open Resource Rejects
0x04 Open Other Rejects
0x05 Close Requests
0x06 Close Format Requests
0x07 Close Other Requests
0x08 Connection Timeouts
Access
Data Type
Get Set
○ UINT
－
○ UINT
－
○ UINT
－
Read out all attribute values from NCW-3DNIP.
Responded Attribute information for the request is following;
ID
0x01 1 (Revision)
0x02 1 (Max Instance)
0x06 0 (Not available for NCW-3DNIP)
0x07 0 (Not available for NCW-3DNIP)
Read out one attribute value from NCW-3DNIP.
Access
Data Type
Get Set
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
○ UINT
－
98
Description
1
1
1
Description
Description
Description
Number of Forward Open service requests received.
Number of Forward Open service requests which
were rejected due to bad format.
Number of Forward Open service requests which
were rejected due to lack of resources.
Number of Forward Open service requests which
were rejected for reasons other than bad format or
lack of resources.
Number of Forward Close service requests received.
Number of Forward Close service requests which
were rejected due to bad format.
Number of Forward Close service requests which
were rejected for reasons other than bad format.
Total number of connection timeouts that have
occurred in connections controlled by the Connection
Manager.
