1-1. Features

(1) High reliability
An absolute position detection format ensures accurate position detection even if a power interruption or
unexpected noise condition occurs. An origin returning operation is not required.
(2) Superior durability
ABSOCODER sensor is not used electronic parts except coils and resistance, and it features a no-contact
construction excepting bearing. This sensor offers problem-free operation, even in environment where it is
exposed to vibration, impact shocks, extreme temperatures, oil, and dust.
(3) Compact design
The unit's outside dimensions (39(W) x 155(H) x 93(D)) were miniaturized. DIN rail can be used, so mounting is
much easier.
(4) EtherNet/IP communication
A position, preset, alarm, and parameter data can be transmitted through the EtherNet/IP network.
- The converter supports full duplex (100BASE-TX), so data can be transmitted faster.
- The minimum cycle for communication is 2ms.
(5) Two axes ABSOCODER sensor can connect
The machine positions for two axes can be detected by one converter. The space-saving in the control panel can
be conducted.
(6) Diagnosis function
The error information can be expressed both by EtherNet/IP alarm data and by monitor LEDs on the converter's
front panel.
(7) Preset function
The position data can be preset to the desired value from the EtherNet/IP master.
(8) Configuration tool (software for configurating the system)
Settings are available by using EtherNet/IP software.
(9) Supporting the device level ring function (DLR)
NCW-3DNIP can connect to the network by ring topology (redundancy) of EtherNet/IP network.
Products with the software version mark put on the products panel after " B " (Ver.2.01) support this function.
Refer to "8-1." for the version mark.
(10) Compliance with CE standards
The converter complies with CE (EMC Directive) standards.
