9-2. Preparation

Prepares that NCW-3DNIP connects the EtherNet/IP network
This manual assumes that NCW-3DNIP and a programmable controller which is manufactured by Rockwell
Automation, Inc. are connected by the network. Therefore, this manual explains a connection method using
following software.
①BOOTP/DHCP Server
②RSLinx Classic
③RSLogix5000
④RSNetWorx
For details of software instruction, refer to each product manual.
●EDS file
If the configuration tool is needed the definition file (EDS file), download it from NSD website.
URL: www.nsdcorp.com
File name: EDS_Rev000000**_NSD_NCW-3D_IP_********.eds
●Hardware Setup
The following figure indicates the connection of NCW-3DNIP as an example.
The NCW-3DNIP is connected to the controller (1769-L30ERM CompactLogix5330ERM) through the EtherNet
switch as shown below.
Programming Terminal
BOOTP/DHCP Server
CompactLogix5330ERM
ABSOCODER Converter
(Windows PC)
Port
&
IP : 192.168.0.60
1769-L30ERM/A
Port
IP : 192.168.0.2
NCW-3DNIP
Port
IP : 192.168.0.100
Ethernet switch
Port
Port
EtherNet/IP
network
Port
