NSD ABSOCODER NCW-3DNIPMP Specifications & Instruction Manual page 24

● Coupling of Turn-type ABSOCODER Sensor
Item
1. Selection of the coupling device should be based on the following
(1) Coupling device
selection precaution
2. If the selected coupling device is larger than necessary (When
3. Be sure to select a coupling device with an adequate
(2) Coupling device
installation
precaution
factors;
- The amount of a mounting error caused by the machine design.
- The permissible error of coupling device.
- Reaction force of coupling device.
- Permissible shaft load of the sensor.
used in high vibration/shock environments), the load which is
applied to the shaft by the vibrations/shocks will be increased by
the weight of the coupling device.
transmission torque surplus relative to the sensor shaft's torque.
Explanation
15
Precaution
The selection of a larger
coupling than necessary
will increase the shaft load
which is caused by the
mounting error amount.
Excessive force applied
to the shaft can deform
the coupling and reduce
durability.
