ID Name
0x09 Mcast Config
0x0A Select ACD
0x0B LastConflictDetected
0x0C EIP Quick Connect
0x0D Encapsulation Inactivity
Timeout
Instance Service (Class ID: 0xF5, Instance ID: 0x01)
ID Name
0x01 Get_Attribute_All
0x0E Get_Attribute_Single
0x10 Set_Attribute_Single
Access
Data Type
Get Set
Structure
－ －
USINT
USINT
UINT
UDINT
BOOL
－ －
Structure
－ －
USINT
USINT[6]
USINT[28]
BOOL
－ －
○ ○ UINT
Read out all attribute values from NCW-3DNIP.
Read out one attribute value from NCW-3DNIP.
Write one attribute value to NCW-3DNIP.
114
Description
NCW-3DNIP doesn't support this attribute.
NCW-3DNIP doesn't support this attribute.
NCW-3DNIP doesn't support this attribute.
NCW-3DNIP doesn't support this attribute.
The TCP socket is cleaned up (closed) when an
encapsulation operation is not detected within the
setting time (second).
Setting range: 0 to 3600s
0: No Timeout detection
Default: 120
This attribute is stored in the non-volatile memory.
Description
(4/4)
