RG-RAP72Pro Installation Guide
Table 1-3 Components on the Rear Panel
No. Component
1 DC power connector
2 Reset button
3 LAN1/2.5G/PoE port
4 LAN2/1G port
5 Label
1.4

Technical Specifications

Table 1-4 Technical Specifications
Radio Design
Wi-Fi Standards
Operating
Frequency Bands
Antenna Type
Spatial Streams
Max. Wi-Fi Speed
Modulation
Receiver Sensitivity
Description
Supplies power to the AP, with a power supply specification of DC 12 V
Press and hold for less than 2 seconds: Restart the device.
Press and hold for more than 5 seconds: Restore the device to factory
settings.
100/1000/2.5GBASE-T port with auto-negotiation, supporting PoE input
100/1000BASE-T port with auto-negotiation
The label is at the bottom of the device.
2.4 GHz: dual-stream
5 GHz: tri-stream
IEEE 802.11a/b/g/n/ac/ax/be
IEEE 802.11b/g/n/ax/be: 2.4 GHz to 2.4835 GHz
IEEE 802.11a/n/ac/ax/be: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725
GHz to 5.850 GHz
Note
The operating band varies in different countries.
Planar inverted-F antenna (PIFA) (2.4 GHz: 2.0 dBi; 5 GHz: 3.0 dBi)
2.4 GHz: two spatial streams, 2x2 MIMO
5 GHz: three spatial streams, 3x3 MIMO
2.4 GHz: 0.688 Gbps
5 GHz: 4.323 Gbps
Combined: 5.011 Gbps
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16QAM@24 Mbps, 64QAM@48/54
Mbps
DSSS: DBPSK@1 Mbps, DQPSK@2 Mbps, CCK@5.5/11 Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM, 4096QAM,
OFDMA
11b: –90 dBm (1 Mbps), –87 dBm (5.5 Mbps), –76 dBm (11 Mbps)
4
Overview
