RG-RAP72Pro Installation Guide
1.5

Power Supply Technical Specifications

The RG-RAP72Pro can be powered by the DC power supply or PoE.

When a DC power adapter is used for power supply, the power adapter should have a voltage of 12 V and a
current of 2.5 A or higher. Dimensions of the DC power connector (outer diameter x inner diameter x depth):
5.5 mm x 2.1 mm x 10 mm (0.22 in. x 0.08 in. x 0.39 in.).

When the AP is powered by standard PoE, the Ethernet cable must be connected to the LAN1/2.5G/PoE port
of the AP, and the other end of the Ethernet cable must be connected to the PoE-capable switch port or a
PoE power sourcing equipment. Ensure that the power sourcing equipment supports IEEE 802.3at.
1.6

Cooling

The RG-RAP72Pro adopts a fanless design.
Caution
Ensure that there is sufficient space around the AP for heat dissipation.
