- Page 1 Ruijie Reyee RG-RAP2260(H) Access Point Hardware Installation and Reference Guide Document Version: V1.1 Date: 2022.12.06 Copyright © 2022 Ruijie Networks...
- Page 2 Ruijie Networks reserves the right to modify the content of the document without any notice or prompt. This manual is designed merely as a user guide. Ruijie Networks has tried its best to ensure the accuracy and reliability of the content when compiling this manual, but it does not guarantee that the content of the manual is completely free of errors or omissions, and all the information in this manual does not constitute any explicit or implicit warranties.
-
Page 3: Preface
Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support The official website of Ruijie Reyee: https://www.ruijienetworks.com/products/reyee Technical Support Website: https://www.ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com... - Page 4 Note An alert that contains additional or supplementary information that if not understood or followed will not lead to serious consequences. Specification An alert that contains a description of product or version support. Note This manual provides installation steps, troubleshooting, technical specifications, and usage guidelines for cables and connectors.
-
Page 5: Table Of Contents
Contents Preface ..............................I 1 Product Overview ..........................1 1.1 About the RG-RAP2260(H) Access Point ................. 1 1.2 Package Contents........................1 1.3 Hardware Features ........................1 1.3.1 Top Panel ........................1 1.3.2 Bottom Panel........................3 1.4 Technical Specifications ......................4 1.5 Power Specifications ......................... - Page 6 3.1 Before You Begin ........................10 3.2 Precautions for Installation ...................... 10 3.3 Precautions for Cabling ......................10 3.4 Installing the Access Point ....................... 11 3.5 Removing the Access Point ..................... 13 3.6 Checking after Installation ....................... 14 4 Verifying Operating Status ......................16 4.1 Setting up Configuration Environment ..................
-
Page 7: Product Overview
Hardware Installation and Reference Guide Product Overview Product Overview About the RG-RAP2260(H) Access Point The RG-RAP2260(H) AX6000 is a ceiling-mount dual-radio access point designed to cover a large indoor area. The access point adopts either IEEE 802.3at/bt PoE power supply or 48 V DC/1 A local power supply. Compliant with the IEEE 802.11a/b/g/n/ac/ax standard, the access point can work in the 2.4 GHz and 5 GHz bands at the same time and supports quad-stream MU-MIMO. - Page 8 Hardware Installation and Reference Guide Product Overview Figure 1-1 Access Point Table 1-2 Status Description The access point is not receiving power. The access point is operating normally but there is an alarm Slow Blinking generated. Possible cases: Restoring the access point to factory settings. Fast blinking Upgrading the firmware.
-
Page 9: Bottom Panel
Hardware Installation and Reference Guide Product Overview 1.3.2 Bottom Panel Figure 1-1 Ports Table 1-3 Bottom Panel Item Description The RESET hole is near the 2.5G/LAN2 port. Press and hold the pin to the RESET hole for less than 2 seconds: Restart the access point. -
Page 10: Technical Specifications
Hardware Installation and Reference Guide Product Overview Technical Specifications Table 1-4 Technical Specifications 2.4 GHz: 4 spatial steams RF Design 5 GHz: 4 spatial steams Standard & Protocol Concurrent 802.11ax, 802.11ac wave2/wave1 and 802.11a/b/g/n 802.11b/g/n/ax: 2.4 GHz to 2.4835 GHz Operating Radio 802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.850 GHz Antenna... -
Page 11: Power Specifications
Hardware Installation and Reference Guide Product Overview Thailand: 2400 MHz to 2483.5 MHz: ≤ 20 dBm 5150 MHz to 5350 MHz: ≤ 23 dBm 5470 MHz to 5725 MHz: ≤ 25 dBm 5725 MHz to 5850 MHz: ≤ 30 dBm Power Adjustment Configurable in increments of 1 dBm Dimensions... -
Page 12: Cooling Solution
Hardware Installation and Reference Guide Product Overview are advised to use an 802.3bt-capable PSE. If you want to use a PoE adapter, a Rujie-certificated PoE adapter is recommended. In a DC power supply scenario, use a 48 V DC/1 A power adapter with a 5.5 mm x 2.1 mm x 10 mm (0.22 in. x 0.08 in. -
Page 13: Preparing For Installation
Hardware Installation and Reference Guide Preparing for Installation Preparing for Installation Safety Precautions Note ● To prevent device damage and physical injury, please read the safety recommendations carefully as described in this chapter. ● Recommendations do not cover all possible hazardous situations. 2.1.1 General Safety Precautions ... -
Page 14: Installation Environment Requirements
Hardware Installation and Reference Guide Preparing for Installation Find the location of the emergency power supply switch in the room before installation. Cut off the power supply first in case of an accident. Be sure to make a careful check before shutting down the power supply. ... -
Page 15: Anti-Interference Requirements
Hardware Installation and Reference Guide Preparing for Installation the relative humidity is low, and might shorten the equipment service life and cause communication failures. The following table shows the maximum concentration and diameter of dust allowed in the equipment room. Maximum Diameter (μm) Maximum Concentration 1.4 ×... -
Page 16: Installing The Access Point
Connectors and Media for the supported wiring for twisted pairs. Avoid bending the cable in a small radius close to the connector. Ruijie recommends that you do not use Ethernet cables with protective sleeves as they could make... -
Page 17: Installing The Access Point
Hardware Installation and Reference Guide Installing the Access Point installation of Ethernet cables more difficult. If the access point adopts PoE power supply, make sure that the power source equipment (PSE) connected to the LAN1/PoE port is 802.3at-capable or 802.3bt-capable. Installing the Access Point Caution ●... - Page 18 Hardware Installation and Reference Guide Installing the Access Point (3) Take out the mounting bracket from the packaging material, and secure the mounting bracket on the ceiling or wall by using self-tapping screws. Figure 3-3 Securing the Mounting Bracket (4) Connect the Ethernet cable to the LAN port on the rear of AP (LAN1/PoE port is PoE-capable). Figure 3-4 Connecting the Ethernet Cable to the LAN Port (5) Align the square feet on the rear of the AP over the mounting holes on the bracket.
-
Page 19: Removing The Access Point
Security Lock is Used (1) If the security lock is used, keep the top of the key against the edge of the mounting bracket (with the Ruijie logo on the key pointed upwards). (2) Slide the key along with the four edges of the mounting bracket, and attempt to insert the key into the keyhole. -
Page 20: Checking After Installation
Hardware Installation and Reference Guide Installing the Access Point Figure 3-7 Removing the Wall Mount AP Figure 3-8 Removing the Ceiling Mount AP Checking after Installation (1) Checking the Access Point ○ Verify that the power source equipment (PSE) connected to the LAN1/PoE port is 802.3at-capable or 802.3bt-capable. - Page 21 Hardware Installation and Reference Guide Installing the Access Point (2) Checking the Power Supply ○ Verify that the power cord is properly connected and compliant with safety requirements. ○ Verify that the access point is operational after power-on.
-
Page 22: Verifying Operating Status
Hardware Installation and Reference Guide Verifying Operating Status Verifying Operating Status Setting up Configuration Environment If the access point is powered by PoE, verify that the power cord is properly connected and compliant with safety requirements. Powering on the Access Point 4.2.1 Checklist before Power-on ... -
Page 23: Monitoring And Maintenance
Hardware Installation and Reference Guide Monitoring and Maintenance Monitoring and Maintenance Monitoring When RG-RAP2260(H) is operating, you can monitor its status by observing the LED indicator. Maintenance If the hardware is faulty, please contact Ruijie technical support for help. -
Page 24: Troubleshooting
Hardware Installation and Reference Guide Troubleshooting Troubleshooting Troubleshooting Procedure... -
Page 25: Appendix
Hardware Installation and Reference Guide Appendix Appendix Connectors and Media 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T Port 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T is a 10/100/1000/2500 Mbps self-adaptive port that supports auto MDI/MDIX Crossover. Compliant with IEEE 802.3bz, 2500BASE-T requires Category 6 or Category 5e 100-ohm UTP or STP (STP is recommended) with a maximum distance of 100 meters (328.08 feet). - Page 26 Hardware Installation and Reference Guide Appendix Figure 7-2 100BASE-TX/10BASE-T Pin Assignments The following figure shows feasible connections of the straight-through and crossover twisted pairs for a 100BASE- TX/10BASE-T port. Figure 7-3 100BASE-TX/10BASE-T Connection...
